Hose Flushing Machine – RG 2, RG 10

Flushing Machine

Hose cleaning machines with two flushing heads – suited for all types of hose and tube assemblies.


RG 2RH 10
DriveDiaphragm pump, 7 bar airDiaphragm pump, 7 bar air
Maximum flow rate25 l/min180 l/min
Pressure filter5 μm10 μm
Air filter5 μm5 μm
Max. air consumption100 Nl/min250 Nl/min
Working rangeup to 1 1/4″ IDup to 2″ ID
Max. length, depending on bore size2,5 m / 8 feet20 m / 65 feet
Tank capacity38 L215 L
Working area350 x 750800 x 1600
Cleaning agentNon-toxic and corrosion-free emulsion, water basedNon-toxic and corrosion-free emulsion, water based
L x W x H (mm)960 x 435 x 9402000 x 840 x 1050
Weight (empty)55 kg160 kg

View our Testing, Control & Flushing Section

Datasheet Download

RG 2, RG 10
