Hydraulic Hose Crimping Machine – UG 32, UG 32 Mobileline

Swaging Machine



Description

UG 20 EcolineUG 20 Mobileline
Crimp force (kN / Ton)190190
Greased machine
ControlControl AControl A
SAE R12 / 4SP* 1 Piece fitting1 1/4″1 1/4″
SAE R15 / 4SH* 2 Piece fitting1 1/4″1 1/4″
SAE R12 / 4SP* 2 Piece fitting1 1/2″1 1/2″
Industrial2″2″
90° Elbows1 1/4″1 1/4″
Max. crimp range70mm70mm
Opening+27mm+27mm
Opening without dies97mm97mm
Master dies length100mm100mm
Type of dies239-xx-Ø239-xx-Ø
Speed (mm/sec) – Close2.01.5
Speed (mm/sec) – Crimp2.00.4
Speed (mm/sec) – Open7.65.7
Noise level69 dBA69 dBA
Drive3 kW1.8 kW
Oil35 L4 L
L x W x H (mm)600 x 550 x 630430 x 370 x 440
Weight150 kg110 kg

* According to the fitting.
